Applications
General downlighting in kitchens, living rooms, dining rooms, reception counters, lobbies.
Installation
Interior and exterior (with IP65 or IP67 rated LED strip).
Material
Aluminium body, PMMA diffuser, aluminium end caps.
Finish
Natural silver anodised or custom powder coat.
Light source
LED ribbon strip.
Power supply
24V DC – remote driver options ranging from 6W up to 320W.
Dimming
Various options available including DALI, 0-10V, DMX – please enquire.
LED strip options vary depending on region – please consult your local distributor for more information. Other LED strip options are available on request, including IP65 and RGBW colour change.
All lumen values refer to the bare LED strip. Losses through diffuser/profile are not represented. Consult photometric data.
5 year manufacturer’s warranty on all LED strip options stated below.
| Watts p/m | Lumens p/m | Colour temp | Code |
|---|---|---|---|
| 2.6W | 270lm | 2700K | SUPER-2.6-27 |
| 280lm | 3000K | SUPER-2.6-30 | |
| 300lm | 4000K | SUPER-2.6-40 | |
| 5W | 470lm | 2700K | SUPER-05-27 |
| 600lm | 3000K | SUPER-05-30 | |
| 640lm | 4000K | SUPER-05-40 | |
| 11W | 1250lm | 2700K | SUPER-11-27 |
| 1270lm | 3000K | SUPER-11-30 | |
| 1400lm | 4000K | SUPER-11-40 | |
| 17W | 2000lm | 2700K | SUPER-17-27 |
| 2000lm | 3000K | SUPER-17-30 | |
| 2130lm | 4000K | SUPER-17-40 | |
| 20.3W | 2190lm | 2700K | SUPER-20.3-27 |
| 2340lm | 3000K | SUPER-20.3-30 | |
| 2460lm | 4000K | SUPER-20.3-40 |
